STARTECH .com video signal converter 4096 x 2160 pixels (HD202A)
- Regular price
- 112.95$
- Sale price
- 112.95$
- Regular price
-
Free shipping
Couldn't load pickup availability
StarTech.com HD202A video signal converter 4096 x 2160 pixels
Brand:StarTech.com
Product name:HDMI Audio Extractor with 4K 60Hz Support
Product code:HD202A
EAN/UPC:
0065030878609
0065030878609, 065030878609
- Separate and send the audio from a 4K HDMI video signal to dedicated audio devices
- Supports the latest HDMI 2.0 specifications and HDR video pass-through
- Hassle-free connection with digital optical audio or Dual RCA audio devices
- Expand the capabilities of the audio extractor by converting to 3.5 mm audio
- Integrated EDID management capabilities with passthrough settings for maximum compatibility
Description
HDMI® Audio De-embedder | HDR | Toslink® Optical Audio | Dual RCA Audio | HDMI Audio
This 4K HDMI audio extractor lets you de-embed the audio from your HDMI video streams to create a distinct audio output that you can connect directly to a digital or analog audio device. Supporting HDMI 2.0 specifications, the de-embedder maintains 4K 60Hz resolutions to deliver a seamless video experience.
4K Video Performance
The HDMI sound splitter supports video resolutions up to 4K 60Hz (3840 x 2160) and high video bandwidth up to 18Gbps. It also supports High Dynamic Range (HDR) video pass-through, letting you enjoy lifelike images with incredible contrast, brightness and color, and greater luminosity compared to standard digital imaging.
Maximum Compatibility
Easily integrate HDMI 2.0 devices, such as your new 4K Blu-ray player, with your existing audio equipment or desktop speakers. The extractor isolates and extracts the audio signal from your HDMI cable and lets you output to digital optical audio or dual RCA audio devices . The integrated EDID management capabilities support 2-channel, 5.1-channel and pass-through audio modes.
The HDCP compliant HDMI audio de-embedder is compatible with dual-RCA composite adapters, giving you the flexibility to integrate the audio from your HDMI source into 3.5 mm audio applications using MU6MMRCA, MU3MMRCA or MUFMRCA (sold separately).
The compact extractor features a small footprint that blends discreetly into your hardware setup, for a uniform look.
HD202A is backed by a 2-year StarTech.com warranty and free lifetime technical support.
This 4K HDMI audio extractor lets you de-embed the audio from your HDMI video streams to create a distinct audio output that you can connect directly to a digital or analog audio device. Supporting HDMI 2.0 specifications, the de-embedder maintains 4K 60Hz resolutions to deliver a seamless video experience.
4K Video Performance
The HDMI sound splitter supports video resolutions up to 4K 60Hz (3840 x 2160) and high video bandwidth up to 18Gbps. It also supports High Dynamic Range (HDR) video pass-through, letting you enjoy lifelike images with incredible contrast, brightness and color, and greater luminosity compared to standard digital imaging.
Maximum Compatibility
Easily integrate HDMI 2.0 devices, such as your new 4K Blu-ray player, with your existing audio equipment or desktop speakers. The extractor isolates and extracts the audio signal from your HDMI cable and lets you output to digital optical audio or dual RCA audio devices . The integrated EDID management capabilities support 2-channel, 5.1-channel and pass-through audio modes.
The HDCP compliant HDMI audio de-embedder is compatible with dual-RCA composite adapters, giving you the flexibility to integrate the audio from your HDMI source into 3.5 mm audio applications using MU6MMRCA, MU3MMRCA or MUFMRCA (sold separately).
The compact extractor features a small footprint that blends discreetly into your hardware setup, for a uniform look.
HD202A is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Specs
Features
Product color
The colour e.g. red, blue, green, black, white.
Black
Audio
Audio output channels
An audio output channel is an electric circuit which acts as a path for a signal produced by a device. A device may have several audio output channels.
5.1 channels
Ports & interfaces
Host interface
Interface that enables a host controller to communicate with a driver.
HDMI
Video in
HDMI
Video out
HDMI
Audio output
The type of audio output that the device produces, and the connector(s).
RCA + Toslink
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
0 - 45 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
The measurement or extent of something from side to side.
80 mm
Depth
The distance from the front to the back of something.
90 mm
Height
The measurement of the product from head to foot or from base to top.
22 mm
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
320 g
Logistics data
Harmonized System (HS) code
85176990
Master (outer) case width
360 mm
Master (outer) case length
608 mm
Master (outer) case height
308 mm
Quantity per master (outer) case
30 pc(s)
Video
Maximum video resolution
This is the maximum resolution of video images. Resolution is a measure of the degree of detail visible.
4096 x 2160 pixels
Video resolutions
The amount of detail that can be seen in the video image.
1280 x 720,1920 x 1080,1920 x 1200,3840 x 2160,4096 x 2160
Maximum refresh rate
60 Hz
Power
External power adapter
Input voltage
The voltage (V) which is required to power the product.
100 - 240 V
Operating voltage
Defines the range of operating voltages available
5 V
Operating current
1 A
Input current
0.4 A
Power plug type
Type M
Packaging data
AC adapter included
Screws included
Number of screws
2
Included power plug types
ANZ, EU, NA, UK
Mounting bracket(s) included
Package width
The distance from one side of the packaging to the other.
157 mm
Package depth
The distance from the front to the back of the packaging.
195 mm
Package height
The distance from the top to the bottom of the packaging.
52 mm
Package weight
Weight of the packaged product in gram.
470 g
